Two sizes, one mechanism
The 135-inch in 16:9 and the 158-inch in 4:3 share the same lift-and-fold frame. The screen folds through 180 degrees into an 1800 mm wide case 1854 mm tall, then rises 700 mm on a 400 W servo column.
135 and 158 inch
| 135 inch | 158 inch |
|---|
| Aspect ratio | 16:9 | 4:3 |
|---|
| Pixel pitch | 1.25 mm | 1.25 mm |
|---|
| Resolution | 2400 × 1350 | 2816 × 1536 |
|---|
| Screen W×H×D | 3000 × 1687.5 × 27.8 mm | 3520 × 1920 × 45 mm |
|---|
| Whole unit W×H×D | 3020 × 1707.5 × 45 mm | 3540 × 1940 × 85 mm |
|---|
| Unfolded width | 3020 mm | 3540 mm |
|---|
| Unfolded height | 2550 mm | 2820 mm |
|---|
| Weight | 430 kg | 580 kg |
|---|
Lift and fold
| Folded height | 1854 mm |
|---|
| Folded screen width | 1800 mm |
|---|
| Lift travel | 700 mm maximum |
|---|
| Folding angle | 180° |
|---|
| Folding seam | 1 mm |
|---|
| Motor | 400 W servo |
|---|
| Drive | Electric / manual |
|---|
| Control | Keypad and remote |
|---|
| Limit | Absolute value recording / NPN three-wire |
|---|
| Driver | Pulse incremental |
|---|
| Motion controller | a1001 / MSP |
|---|
| Relay | Solid state 10 A / 40 A |
|---|
| Control signal | TCP network |
|---|
| Host software | XM control system |
|---|
| Anti-tilt | External four-axis guide set |
|---|
| Hinge | Precision aluminium alloy |
|---|
| Back frame | Aluminium / stainless steel |
|---|
| Covers | Sheet metal / resin |
|---|
| Castor spacing | 1417 mm |
|---|
System
| Operating system | Colorlight Android 10.0 |
|---|
| CPU | ARM Cortex-A73 dual core + Mali-450 five core GPU |
|---|
| Memory | 3 GB |
|---|
| Storage | 16 GB |
|---|
| Audio | 2 × 20 W built in |
|---|
| OPS (optional) | i7-8550U, 8 GB RAM, 256 GB SSD, Windows 10 Pro 64-bit |
|---|
| Maintenance | Front maintenance |
|---|
Questions asked before ordering
Does it fit through a lift door?
Folded, the unit stands 1854 mm high — under the 2 m door height that passenger lifts clear.
How high does the picture go?
The column travels 700 mm. Unfolded, the unit stands 2550 mm on the 135 and 2820 mm on the 158 before the lift is added.
